I. General Description
This machine is used to dispense the PVC in the end caps of the spin-on filters.
II. Main Features
1.This equipment adopts double-screw pump to measure and quantitatively inject glue.
2.The capacity of glue storage tank is 200L, with stirring function on the top of the tank.
3.Integrated double turntable feeding, the width of the conveyor belt positive and negative screw handwheel to adjust the size.
4.Feeding turntable adopts servo motor drive, four-station one piece feeding disk, moon shaped baffle plate adopts quick change structure.
5.Action: manually put the end cap on the conveyor belt into the turnta
ble inlet, the turntable to the injection station, the system automatically quantitative spit glue, the turntable rotates to the lower station, the product from the discharge chute out.
Ⅲ.Technical Specifications
Production efficiency | 50pairs/min |
Sealing cap diameter | 60-110mm |
Glue tank capacity | 15kg |
Air pressure | 0.5Mpa |
Power supply | 220V/50Hz |
Motor power | 0.75KW |
Machine weight | 400kg |
Machine size | 1020mm*600mm*700mm (L*W*H) |
