Main Features
1. Automatically finish the action of compositing ron wire together with non-woven fabric, neat and frm products got with easy operation and high eficiency.
2. Adjust working speed by freguency converter, suitable in any producing conditions.
3. The gluing temperature can be set to adiust freely.
Technical Parameter
Production capacity | 3 meters/minute |
Material width | ≦700mm |
Material roll diameter | ≦800mm |
Heating power | 3kw |
Motor power | 0.75kw |
Power supply voltage | 380V/50Hz |
Machine weight | 500kg |
Working air pressure | 0.6MPa |
